12V/48W 24V/96W 1 Channel Touch Line LED Dimmer for Single Color Strips

https://www.qskj.cc/web/image/product.template/663/image_1920?unique=ea656d2
(0 review)

12.01 12.01 USD 12.01

¥ 86.90

Not Available For Sale


  • Voltage
  • Color

This combination does not exist.


SKU :
1920500
Share :
100% original guarantee
Return within 30days
Worldwide Fast delivery

Features:

The LED dimmer adopts capacitance touch technique: switch and dimming function can be realized by touching, dim 12V-24V directly driven LED lighting products, such as LED cabinet light, LED rigid bar, LED strip and LED panel light. It can be used as on/off touch switch. During the dimming process, it doesnt flicker.

Specifications:

Working voltage

DC12-24V

Working temperature

-20℃~+60

Output

1 CH

Max output current

4A

Static power

<1w<><1w<>

Output power

12V<48w,24v<96w<><48w,24v<96w<>

Packing size

160*90*15mm

N.W &G.W:

30g&35g

Function

can realize stepless dimming

Instruction:

  • The finger touches dimmer plastic body.

  • The touch time is less than 3 second, it is on/off switch.

  • The touch time is more than 3 second, it is dimming function, the brightness will be raised to the highest or fallen to the lowest.

Voltage 12V or 24V
Color Black or White
