LED Amplifier RF Remote RGB Controller for LED Strip Light

Feature:

• Ultra slim desigb

• Simple installation

• High efficiency, low heat

• Wide working voltage

• Up to 3*4A peak current

• Own embedded control IC Chip

• Wrong wiring protection

• Infinite cascading ability

Specifications:

• Voltage:DC5-24V

• Current:4A *3CH

• Power Dissipation:<0.5W

• Work Temperature:-20~+60degree

• Power output: 12V-144 W,24V-288W

• Power connector: double lines

• LED Connector: 4-pin

• Supper Mini, safe,easy to operate.

• Can be used for SMD 3528 Led strip light, SMD 5050 Led strip light

Application:

• The input voltage of this controller should be follow the specifications, other high voltage would most probably destroy it

• The 4wires coming out of the controller can’t be incorrectly interconnected or short circuit could occur

• Connect the wires of the controller and LED fittings as per the instruction

• Don’t peel off the label on the controller in case any indication information will be missed

• The standard warranty is one yeas Our company won’t be responsible for any damage of the Controller due to any wrong operation.

Package include:

• 1* R103-WS 4pin mini rgb led amplifier
