CREE XHP70.2 XHP-70 2 Generation Cool White Neutral White Warm White LED Emitter 6V 12V with 16mm 20mm Copper PCB

Price:

6.81


5W CREE XTE S3 High Power LED 8-20mm PCB Emitter Warm Neutral White Blue
5W CREE XTE S3 High Power LED 8-20mm PCB Emitter Warm Neutral White Blue
1.06
1.06
30W 40W 50W Driverless LED Light COB Chip Spotlight Size 110x58mm Emitting 60x30mm
30W 40W 50W Driverless LED Light COB Chip Spotlight Size 110x58mm Emitting 60x30mm
5.12
5.12

CREE XHP70.2 XHP-70 2 Generation Cool White Neutral White Warm White LED Emitter 6V 12V with 16mm 20mm Copper PCB

https://www.satisled.com/web/image/product.template/2006/image_1920?unique=31bf110
(0 review)

13.16 13.16 USD 13.16

¥ 84.70

Not Available For Sale


  • Emitting Color
  • Finish
  • Voltage

This combination does not exist.


Categories :
XHP 35-50-70 Series
SKU :
1817374
Share :
100% original guarantee
Return within 30days
Worldwide Fast delivery

Description:

  • Maximum drive current: 4800mA (6V), 2400mA (12V)

  • 7mm x 7mm

  • Maximum light output: up to 4022lm 32W

  • Low thermal resistance: 0.9°C/W

  • White

  • Binned at 85º

  • Wide angle: 120º

  • Unlimited floor life at ≤ 30ºC/85% RH

  • Reflow solderable - JEDEC J-STD-020C

  • Electrically neutral thermal path

XLamp XHP70.2

Next Generation of Extreme High Power LEDs

 The XLamp® XHP70.2 LEDs is the next generation of Extreme High Power LEDs that deliver the lowest system cost through the best lumen density, reliability and color consistency. Built on Cree’s latest high power LED technology, the XHP70.2 LED improves the lumen density, voltage characteristics, reliability and optical performance of the XHP70 LED in the same 7.0mm x 7.0mm package. The new XHP70.2 LED provides an easy drop-in upgrade to achieve higher system LPW for lighting manufacturerswith existing XHP70 designs, eliminating redesign costs. Its unparalleled lumen density and longer lifetime at higher operating temperatures also enables new and innovative lighting designs at lower system costs.


Emitting Color Warm White 3000K or Neutral White 5000K or Cool White 6000-6500K
Finish 16mm DTP Copper PCB or 20mm DTP Copper PCB
Voltage 6V or 12V
