2-Channel Constant Voltage PWM LED DMX512 Decoder Controller LED Bulb Lamps
Categories :
DMX controllerSKU :
1920195
100% original guarantee
Return within 30days
Worldwide Fast delivery
Summary:
DMX512 constant voltage decoder which is developed only for constant voltage LED lamps. It adopted advanced micro-computer control technology to transfer standard DMX512/1990 signal to PWM signal. User can choose 1-2 output channels, max 8A output each channel, 4096 grey scales. It can be used as DMX512 master or as DMX decoder to connect computerized digital output consol with analog silicon case and controls LED lamps of architecture and lighting.
Specifications:
Input voltage | DC12V~DC24V |
Max load current | 8A/CH*2 |
Max output power | 192W(12V), 384W(24V) |
Input signal | DMX512/1990 |
Output signal | Constant Voltage PWMx2 |
Grey scale | 4096 levelsx2 |
Decode channel | 2CH |
DMX512 socket | Terminal block |
Product size | L176*W46*H30mm |
